MITSUBISHI W20500100 high-precision industrial encoder
Description:
Manufacturer : MITSUBISHI
Product No. : W20500100
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The MITSUBISHI W20500100 is a high-precision industrial encoder designed to deliver accurate position, speed, and motion feedback for a wide range of industrial automation applications. As a core product in MITSUBISHI’s industrial sensor lineup, the W20500100 combines robust construction, reliable performance, and flexible integration, making it ideal for use in CNC machines, robotics, conveyor systems, and other harsh industrial operating environments. This page provides detailed technical specifications, functional features, and application information to help you fully understand the capabilities of the MITSUBISHI W20500100 industrial encoder.
Detail:
|
Specification
|
Value
|
|
Product Model
|
MITSUBISHI W20500100
|
|
Product Type
|
Rotary Industrial Encoder
|
|
MITSUBISHI Reference Number
|
W20500100 (Original Equipment Part)
|
|
Encoding Type
|
Optical Incremental Encoder
|
|
Resolution
|
1000 Pulses per Revolution (PPR)
|
|
Output Signal
|
Differential Line Driver (A, /A, B, /B, Z, /Z)
|
|
Supply Voltage
|
10-30 VDC (±10% tolerance)
|
|
Electrical Connection
|
M12 x 1, 8-pole male connector
|
|
Shaft Diameter
|
6 mm (solid shaft, stainless steel)
|
|
Operating Temperature Range
|
-10 °C to +70 °C (14 °F to +158 °F)
|
|
Protection Class
|
IP65 (dust-tight and protected against water jets)
|
|
Weight
|
Approx. 0.28 kg
|
|
Feature
|
Benefit
|
|
High Precision Resolution
|
1000 PPR resolution ensures accurate position and speed feedback, enabling precise control of industrial machinery and automation systems, reducing errors and improving production efficiency.
|
|
Robust Optical Sensing
|
Optical sensing technology provides stable performance and resistance to interference, ensuring reliable operation in harsh industrial environments with dust, vibration, and temperature fluctuations.
|
|
Differential Output Signal
|
Differential line driver output (A, /A, B, /B, Z, /Z) minimizes signal interference over long cable runs, ensuring accurate data transmission even in noisy industrial settings.
|
|
Wide Supply Voltage Range
|
10-30 VDC supply voltage with ±10% tolerance allows flexible integration into various industrial power systems, reducing compatibility issues and simplifying installation.
|
|
Compact & Lightweight Design
|
Compact form factor and 0.28 kg weight facilitate easy installation in tight spaces, ideal for use in small CNC machines, robotics, and compact automation equipment.
|
|
IP65 Protection
|
IP65 protection class safeguards the encoder from dust and water jets, ensuring long service life and reliable performance in harsh industrial environments such as manufacturing plants and warehouses.
|
|
Standard M12 Connection
|
8-pole M12 male connector enables quick and secure wiring, simplifying installation and maintenance, and ensuring compatibility with standard industrial connection systems.
|
